PRODUCT

    GRIPKIT-E1

    KEY FEATURES




    • contains everything you need for a handling application
    • ready to use and works within minutes („plug & work“)
    • compatible with all models by Universal Robots
    • precise. reliable and durable technology
    • Several sizes to cover the broadest application range of today‘s available UR+ products
    • Servo-electric
    • Smart Pneumatics
    • Gripping forces from 7.5 N to 550 N





    TECHNICALSPECIFICATIONS


    Specification or Feature
    Value / Comments
    Workpiece material
    GRIPKIT-E1
    GRIPKIT-E2
    Actuation
    Servo-electric
    Servo-electric
    Gripper type
    Parallel
    Parallel
    Gripping force
    adjustable 7.5 to 30 N
    adjustable 50 to 200 N
    Max. Payload (form fit/friction fit)
    2.7 kg / 0.15 kg
    4.3 kg / 1 kg
    Total stroke
    20 mm
    30 mm
    Weight
    0.38 kg
    0.87 kg
    Included gripper
    IEG 55-020
    IEG 76-030
    Parameter sets
    4 grips
    4 grips
