PRODUCT

    FORCEKIT

    KEY FEATURES




    • Uncompromising Performance
    • Seamless integration
    • Intelligent measuring in all axes
    • High Performance and Reliability
    • Multiple applications





    TECHNICALSPECIFICATIONS


    Specification or Feature
    Value / Comments
    Measurement range
    ±120 N / ±3 Nm
    Effective Resolution
    0.005 N / 0.001 Nm
    Max. Overload
    Mz: 5x, others 10x full scale
    Absolute Accuracy
    ±1.5 % typ
    Repeatability
    0.5 %
    Sampling rate
    500 Frames/s
    Sampling resolution
    16 Bit
    Power supply
    24 VDC ±10 %, 1.9 W typ.
    Weight
    520 g
    Protection class
    IP 40
    Temperature range
    5 to 50 °C
