PRODUCT

    QUICK CHANGER

    QUICK CHANGER DATASHEET




    • Quickly change of tools, flange standard ISO9409-1, type 50-4-M6
    • Optimized for collaborative applications
    • 10 kg rated payload
    • Patented reliable and easy-to-use locking mechanism
    • Redundant locking structure and locking springs





    TECHNICALSPECIFICATIONS


    Technical data
    Min
    Typical
    Max
    Units
    Technical data
    Value / Comments
    Permissible force
    -
    -
    400*
    [N]
    Permissible torque
    -
    -
    50*
    [Nm]
    Rated payload
    -
    -
    10
    22
    [kg]
    [lbs]
    Weight (robot-part)
    -
    0.062
    0.137
    -
    [kg]
    [lbs]
    Weight (tool-part)
    -
    0.140
    0.308
    -
    [kg]
    [lbs]
    Combined weight
    -
    0.202
    0.445
    -
    [kg]
    [lbs]
    Combined height
    -
    24.10
    0.95
    -
    [mm]
    [in]
    Angle difference
    -
    22.5
    0.3927
    -
    [Deg.]
    [Rad.]
    Repeatability
    -
    -
    ±0.02
    [mm]
    Tool change
    -
    5.000
    -
    [cycles]
    Robot operation
    10
    -
    -
    [M cycles]
    Permissible force
    -
    -
    400*
    [N]
